*Using hidden scissor structure, small footprint
*Hydraulic cylinder volume synchronization platforms running simultaneously and smoothly
*Has a hydraulic lock and mechanical dual-gear safety claw double safety device, automatically turns down, by locking operation can be achieved by describing the insurance claw positioning, safe and reliable
*Uses oil-free ultra-resistant material sliding blocks
*Using integrated base so that the horizontal adjustment capability, precisely adjustable horizontal accuracy, especially for the detection of wheel alignment
|
Lifting Capacity |
4.0 Ton |
|
Max. Lift.Height(Mother Scissors) |
1850 mm |
|
Max. Lift.Height(Child Scissors) |
450 mm |
|
Total Length |
4980 mm |
|
Power Supply |
380 V |
|
Power |
2.2 kw |
| Net Weight |
2150 kgs |
| Gross Weight |
2230 kgs |
